We’ve been busy creating new videos here at PLCGurus.NET! We decided to do a piece for those of you who may be new to the Allen-Bradley family of PLC’s and Rockwell Software in general. In the following set of videos I will show you how to install FREE Rockwell software.
That’s right, Rockwell does provide a FREE set of tools to get you up and running on their RSLogix 500 platform and MicroLogix 1100 platform of controllers without the need to spend any $$$ at all!
The MicroLogix 1100 Controller is a powerful low cost controller that adds embedded EtherNet/IP (typically found in larger, more expensive controllers), on-line editing, and an LCD panel for quick setup and configuration.
The built-in LCD panel shows controller status, I/O status, and simple operator messages. With 2 analog inputs, 10 digital inputs and 6 digital outputs, the MicroLogix 1100 controller can handle a wide variety of tasks.
What Software Are You Going To Need?
There are 3 key pieces of software we are going to need in order to get up and running – the best part they are all completely free! Not only do we get free Rockwell software, we will be able to fully develop, download, upload, debug, run and test your PLC programs without buying any hardware or software at all.
So what are we going to need exactly:
- RSLogix500 Micro Lite v8.3
- RSLinx Lite v2.57
- RSLogix Emulate 500 v6.00
So what are we waiting for…let’s get started!
Locating And Downloading Your Free Software!
You would think this step would be somewhat easy, however, if you’ve ever visited the Rockwell Automation website you’ll quickly learn that even some of the simpler tasks…like this one, can prove somewhat challenging. Perhaps I’m being a little too hard on Rockwell here, they are making some really great improvements to their site, however, this has left a lot of “broken” links around the internet as result of some of the reorganization and rearrangement of things.
For this, I will reference Rockwell Knowledge Technote 63956, so I recommend if you don’t currently have an account setup, you should do so now – it’s FREE!
Skip The Verb-age And Watch How To Download Free Rockwell Software On YouTube!
Okay, I assume you have your account setup now…Great! Now, to download the free Rockwell software we need, do the following:
- Go to Product Compatibility and Download Center (PCDC)
- At the top of the screen search for MicroLogix 1100 then Select firmware 10.000.
- From selection choose Select Files option: Select RSLogix Micro Starter Lite w/o RSLinx EN
- Select RSLogix Micro Starter Lite w/o RSLinx EN, RSLogix Emulate 500, and RSLinx Classic Lite for MicroLogix.
Then click the Download Now button:
You’ll then be prompted to log in using the account you created above and will have the option to download the files either via their Download Manager or Direct Download after accepting their license terms.
On that’s just about it! Want to see the complete the complete How To video on our YouTube Channel. Check it out below and don’t forget to subscribe to our channel!
Installing RSLogix 500, RSLinx, and RSLogix Emulate
Rockwell Panelbuilder32 software, free download Windows 7
Installing the software really is no more difficult than installing any standard software package. The first thing you will need to do is the self-extracting .exe (.rar) files you downloaded above. Once extracted you can simply double click the Setup files to begin the installation. Eee the complete the complete How To video on our YouTube Channel. Check it out below and don’t forget to subscribe to our channel!
Allen Bradley Panelbuilder32 Download
Watch How To Install Free Rockwell Software Live On YouTube!
Setting Up And Using RSLogix Emulate 500
Finally, we’ve arrived! Learn how to configure the RSLogix Emulate 500, RSLinx and write a simple program in RSLogix Micro Starter Lite. This video will show you all the settings and configuration necessary to get you up and running quickly with this free Rockwell software!
Watch How To Use Free Rockwell Software Live On YouTube!
Final Words…
I certainly hope you’ve enjoyed this article and I do encourage you to become a member of our growing community of professional engineers, technicians and technologists, Register Here!
Also, check out our YouTube Channel to see some great videos…and don’t forget to like and subscribe to our channel!
